A large variety of PCB-based antenna structures are used at microwave frequencies, and some are used at higher frequencies.
A common PCB antenna structure is a microstrip patch antenna. A microstrip structure is a two-layer copper circuit with a signal plane and a ground plane, but it is more common for this type of circuit to be the outer layers of a multilayer circuit.
