pSemi Announces Frequency Extension and Volume Production of the 55 GHz Digital Step Attenuator (DSA)

Originally Unveiled as a 50 GHz DSA, the PE43508 Proves Its Superior Performance Extends to an Unprecedented 55 GHz

pSemi Corporation (formerly Peregrine Semiconductor), a Murata company focused on semiconductor integration, announces volume production of the PE43508 digital step attenuator (DSA). This mmWave product is the world’s first single-chip silicon-on-insulator (SOI) DSA to support the entire 9 kHz to 55 GHz frequency range. Ideal for 5G test and measurement applications, the PE43508 exemplifies pSemi’s high-performance capabilities at mmWave frequencies. The 55 GHz DSA maintains a monotonic response across the entire frequency range and features low insertion loss, low attenuation error and good return loss.

The PE43508 has an extended temperature range from −40°C to +105°C, an HBM ESD rating of 1 kV and an easy-to-use digital control interface supporting both serial addressable and parallel programming. The DSA supports 1.8 V control signals and has an optional VSS_EXT bypass mode.The PE43508 is a 6-bit, 50-ohm DSA that offers wideband support from 9 kHz to 55 GHz. The PE43508 covers a 31.5 dB attenuation range in 0.5 dB and 1 dB steps, and it is capable of maintaining 0.5 dB and 1 dB monotonicity through 55 GHz. The PE43508 also delivers glitch-safe attenuation state transitions, meaning no increased power spike during a state transition.

The PE43508 has an extended temperature range from −40°C to +105°C, an HBM ESD rating of 1 kV and an easy-to-use digital control interface supporting both serial addressable and parallel programming. The DSA supports 1.8 V control signals and has an optional VSS_EXT bypass mode.

Offered as a flip-chip die, volume-production parts, evaluation kits and samples are available now.
